OcNOS Hardware Compatibility List
How to use this page
- Narrow the list using filters for Manufacturer, ASIC and Switch Capacity.
- Filters are dynamic with each use, and can be combined for more specific subsets of data.
- Use the Search box in the table to narrow down hardware platforms.
- By port speed. Example: search on ‘400GE’
- By OcNOS SKUs. Example: search on ‘-DC’
- By platforms. Example: search ‘UfiSpace’
- Sorting and searching can be used separately or together.
- Available hardware datasheets are linked in the first column. These are for general reference and can become out of date. Check platform vendor websites for the most current versions.
- Available supported cables and transceivers for each model are linked in the last column.
- Use the Reset Filters button to reset the page.
Download PDF: Filtered List Full List
| PLATFORM MODEL | PLATFORM VENDOR | ASIC | ASIC MODEL | SWITCH CAPACITY | PORTS | SKU | CURRENT SUPPORTED | HARDWARE REVISION | CABLES AND TRANSCEIVERS |
|---|---|---|---|---|---|---|---|---|---|
| S9500-22XST | UfiSpace | QAX | BCM88470 | 300Gbps | 2 x 100GE 8 x 25GE 8 x 10GE 4 x 1GE RJ45 | OcNOS-SP-CSR-300 OcNOS-SP-IPBASE-300 OcNOS-SP-MPLS-300 | SP 6.6.0 | CPU CPLD version : 21 BMC : A speed AST2400 BMC Firmware Revision : 4.07 Diag Version : DIAG_DNX_4.0.10 ONIE Version : 2021.02v03 Label Revision : N/A Main Board CPLD Version : 2 Device Version : 255 | Cables & Transceivers |
| S9500-30XS | UfiSpace | QAX | BCM88470 | 300Gbps | 20 x 10GE 8 x 25GE 2 x 100GE | OcNOS-SP-CSR-300 OcNOS-SP-IPBASE-300 OcNOS-SP-MPLS-300 | SP 6.6.0 | Label Revision: CMM2Y00DRA CPU CPLD version:21 Main Board CPLD Version : 13 BMC Firmware Revision: 3.14 Diag Version: DIAG_DNX_3.1.9 ONIE Version: 2017.08v04 | Cables & Transceivers |
| S9501-18SMT | UfiSpace | QUX | BCM88272_A1 | 64Gbps | 6 x 10GE 8 x 1GE 4 x 1GE Base-T RJ45 | OcNOS-SP-CSR-64 OcNOS-SP-IPBASE-64 OcNOS-SP-MPLS-64 | SP 6.6.0 | Label Revision : N/A Device Version : 2 Main board CPLD version : 19 BMC : A speed AST2600 BMC Version : 4.16 BMC AUX Version : 0x00.0x00.0x00.0x00 Diag Version : DIAG_DNX_4.1.4 ONIE version : 2021.02v06 | Cables & Transceivers |
| S9501-28SMT | UfiSpace | QUX | BCM88270 | 120Gbps | 8 x 10GE 16 x 1GE 4 x 1GE Base-T RJ45 | OcNOS-SP-CSR-120 OcNOS-SP-IPBASE-120 OcNOS-SP-MPLS-120 | SP 6.6.0 | Label Revision : N/A Main board CPLD version: 19 BMC : A speed AST2600 BMC Firmware Revision : 4.16 Diag Version : DIAG_DNX_4.0.27 ONIE Version : 2021.02v06 | Cables & Transceivers |
| S9502-12SM | UfiSpace | QUX | BCM88273 | 32Gbps | 8 x 1GE SFP 4 x 10GE SFP+ | OcNOS-SP-CSR-32 OcNOS-SP-IPBASE-32 OcNOS-SP-MPLS-32 | SP 6.6.0 | Device Version : 2 Label Revision : N/A ONIE Version : 2022.02v02 Diag Version : DIAG_DNX_4.0.40 Switch Chip Revision : BCM88273_A1 Main Board CPLD Version : 19 Version : SIADLite_C3000_SERIES_R02.11 | Cables & Transceivers |
| S9502-16SMT | UfiSpace | QUX | BCM88273_A1 | 32Gbps | 4 x 10GE 8 x 1GE 4 x 100M/1000 Base-T RJ45 | OcNOS-SP-CSR-32 OcNOS-SP-IPBASE-32 OcNOS-SP-MPLS-32 | SP 6.6.0 | Label Revision: N/A Main board CPLD version: 19 BMC: A speed AST2600 BMC Firmware Revision: N/A Diag Version : DIAG_DNX_4.0.41 Device Version : 2 Label Revision : N/A ONIE Version : 2022.02v02 | Cables & Transceivers |
| S9510-28DC | UfiSpace | Q2A | BCM88483 | 800Gbps | 2 x 100GE/400GE 2 x 40GE/100GE 24 x 10GE/25GE | OcNOS-SP-IPBASE-800 OcNOS-SP-MPLS-800 OcNOS-SP-PLUS-800 | SP 6.6.0 | Label Revision : N/A BMC : A speed AST2620 BMC Firmware Revision : 4.17 ONIE Version : 2021.02v05 Main Board CPLD Version: 5 Diag Version : DIAG_DNX_4.0.37 | Cables & Transceivers |
| S9510-30XC | UfiSpace | Q2U | BCM88280 | 300Gbps | 28 x 1GE/10GE/25GE SFP28 2 x 40GE/100GE QSFP28 with FlexE support | OcNOS-SP-IPBASE-300 OcNOS-SP-MPLS-300 OcNOS-SP-PLUS-300 | SP 6.6.0 | Device Version : 1 Label Revision : N/A Diag Version : DIAG_DNX_4.1.4 ONIE Version : 2022.02v04 BMC Version : 4.16 BMC AUX Version : 0x00.0x00.0x00.0x00 | Cables & Transceivers |
| S9600-32X | UfiSpace | Q2C | BCM88820 | 2.4Tbps | 32 x 100GE 4 x 25GE | OcNOS-SP-IPBASE-2400 OcNOS-SP-MPLS-2400 OcNOS-SP-PLUS-2400 | SP 6.6.0 | Firmware Revision : 3.33 MASTER CPLD : 27 Label Revision : N/A ONIE Version : 2022.02v04 Diag Version : 0.2.2 Switch Chip Revision : BCM88820_A1 MASTER CPLD : 27 Main Board ID : 27 | Cables & Transceivers |
| S9600-56DX | UfiSpace | Q2C | BCM88820_A1 | 4.8Tbps | 48 x 100GE QSFP28 8 x 400GE QSFP-DD | OcNOS-SP-IPBASE-4800 OcNOS-SP-MPLS-4800 OcNOS-SP-PLUS-4800 | SP 6.6.0 | Label Revision : N/A MASTER CPLD version: beta BMC Firmware Revision: 2.31 ONIE Version : 2022.02v03 CPLD1 Version : 2 CPLD2 Version : 1 CPLD3 Version : 1 CPLD4 Version : 1 CPLD5 Version : 1 Diag Version : 0.1.3 | Cables & Transceivers |
| S9600-64X | UfiSpace | Q2C | BCM88820 | 4.8Tbps | 64 x 100GE 4 x 25GE | OcNOS-SP-IPBASE-4800 OcNOS-SP-MPLS-4800 OcNOS-SP-PLUS-4800 | SP 6.6.0 | Device Version : 1 Label Revision : N/A Firmware Revision : 3.33 Switch Chip Revision : BCM88820_A1 MASTER CPLD : 11 Main Board ID : 11 ONIE Version : 2022.02v04 Diag Version : 0.1.10 | Cables & Transceivers |
| S9110-32X | UfiSpace | TR3-X7 | BCM56870 | 3.2Tbps | 32 x 40/100 QSFP28 | OcNOS-DC-IPBASE-3200 OcNOS-DC-PLUS-3200 | DC 6.6.0 | Firmware Revision : 3.33 MASTER CPLD : 27 Label Revision : N/A ONIE Version : 2022.02v04 Diag Version : 0.2.2 Switch Chip Revision : BCM88820_A1 MASTER CPLD : 27 Main Board ID : 27 | Cables & Transceivers |
| S9600-28DX | UfiSpace | Q2C | BCM88820 | 2.4Tbps | 4 x 40/100/400G QSFP-DD 24 x 40/100G QSFP28 | OcNOS-SP-IPBASE-2400 OcNOS-SP-MPLS-2400 OcNOS-SP-PLUS-2400 | SP 6.6.0 | Device Version : 1 Label Revision : N/A ONIE Version : 2022.02v03 Diag Version : 0.1.8 BMC Version : 2.31 CPLD1 Version : 2 CPLD2 Version : 1 CPLD3 Version : 1 | Cables & Transceivers |
| S9600-72XC | UfiSpace | Q2C | BCM88820 | 2.4Tbps | 8 x 100GE 64 x 25GE 2 x 10GE | OcNOS-SP-IPBASE-2400 OcNOS-SP-MPLS-2400 OcNOS-SP-PLUS-2400 | SP 6.6.0 | ONIE Version : 2022.02v04 Diag Version : 0.5.3 Switch Chip Revision : BCM88820_A1 MASTER CPLD : 35 Main Board ID : 35 Extend Board ID Version : 9 BMC Version : 3.03 BMC AUX Version : 0x00.0x00.0x00.0x00 | Cables & Transceivers |
| S6301-56ST | UfiSpace | TR3-X2 | BCM56277_A1 | 120 Gbps | 48 x 1G Base-T 8 x 10G SFP+ | OcNOS-DC-MGMT-120 OcNOS-DC-IPBASE-120 | DC 6.6.0 | Label Revision : N/A Board CPLD Version : 0.3 ONIE Version : 2022.02v02 Diag Version : DIAG_DNX_4.1.8 Device Version : 2 | Cables & Transceivers |
| S8901-54XC | UfiSpace | TR3-X5 | BCM56770_A0 | 2 Tbps | 6 x 40/100G QSFP28 48 x 1/10/25G SFP28 | OcNOS-DC-IPBASE-2000 OcNOS-DC-PLUS-2000 | DC 6.6.0 | Device Version : 3 Label Revision : N/A ONIE Version : 2022.02v05 Diag Version : 0.1.9 Switch Chip Revision : BCM56770_A0 CPLD 1 Version : 0.2 CPLD 2 Version : 0.1 BMC Version : 11.08 BMC AUX Version : 0x00.0x00.0x00.0x00 | Cables & Transceivers |
| S9610-36D | UfiSpace | J2C+ | BCM88850_A1 | 14.4 Tbps | 36 x 400G QSFP-DD | OcNOS-SP-IPBASE-14400 OcNOS-SP-MPLS-14400 OcNOS-SP-PLUS-14400 | SP 6.6.0 | Device Version : 2 Label Revision : N/A ONIE Version : 2022.02v02 Diag Version : 0.1.3 Switch Chip Revision : BCM88850_A2 CPLD 1 Version : 0.1 CPLD 2 Version : 0.1 CPLD 3 Version : 0.1 BMC Version : 2.39 BMC AUX Version : 0x00.0x00.0x00.0x00 | Cables & Transceivers |
| S9300-32D-4 | UfiSpace | TR4 | BCM56880_B0 | 1.28 Tbps | 32 x 40/100/200/400G QSFP-DD ports w/ 400G ZR/ZR+ support 2 x 1/10G SFP+ ports | OcNOS-DC-IPBASE-12800 OcNOS-DC-PLUS-12800 | DC 6.6.0 | Device Version : 13 Label Revision : N/A ONIE Version : 2022.02v04 Diag Version : 2.1.4 BMC Version : 12.06 BMC AUX Version : 0x00.0x00.0x00.0x00 | Cables & Transceivers |
| AS5835-54T | Edgecore | TR3-X5 | BCM56277 | 1.08Tbps | 48 x 10G RJ45 6 x 100G QSFP28 | OcNOS-DC-IPBASE-1080 OcNOS-DC-PLUS-1080 | DC 6.6.0 | Label Revision: R01C CPLD 1 Version : 3 CPLD 2 Version : 2 CPLD 3 Version : 4 Fan CPLD Version : 1 | Cables & Transceivers |
| AS5835-54X | Edgecore | TR3-X5 | BCM56771 | 1.08Tbps | 48 x 10GE SFP+ 6 x 100GE | OcNOS-DC-IPBASE-1080 OcNOS-DC-PLUS-1080 | DC 6.6.0 | Label Revision: R0BA CPLD 1 Version : 3 CPLD 2 Version : 2 CPLD 3 Version : 2 Fan CPLD Version : 1 Diag Version : 01.01.02.03 ONIE Version : 2019.08.00.01 | Cables & Transceivers |
| AS5912-54X | Edgecore | QMX | BCM88370 | 800Gbps | 48 x 10GE 6 x 100GE | OcNOS-SP-IPBASE-800 OcNOS-SP-MPLS-800 | SP 6.6.0 | Label Revision: R02B CPLD 1 Version: 9 CPLD 2 Version: 6 Fan CPLD Version: 2 ONIE Version : 2018.05.00.04 Diag Version : 0.0.5.9 | Cables & Transceivers |
| AS5915-18X | Edgecore | QUX | BCM88272 | 64Gbps | 6 x 10GE 8 x 1GE 4 x 100/1000 Base-T RJ45 | OcNOS-SP-CSR-64 OcNOS-SP-IPBASE-64 OcNOS-SP-MPLS-64 | SP 6.6.0 | Label Revision : R01 ONIE Version : 2020.05.00.03 Diag Version : 01.01.01.26 Switch Chip Revision: BCM88272_A1 CPLD Version : 1 FPGA Version : 46 Fan CPLD Version : 0 | Cables & Transceivers |
| AS5916-54XKS | Edgecore | QMX | BCM88375 | 800Gbps | 48 x 10GE 6 x 100GE | OcNOS-SP-CSR-800 OcNOS-SP-IPBASE-800 OcNOS-SP-MPLS-800 | SP 6.6.0 | Label Revision: R03D CPLD 1 Version: 14 CPLD 2 Version: 6 Fan CPLD Version: 3 | Cables & Transceivers |
| AS5916-54XKS-OT | Edgecore | QMX | BCM88375_B0 | 800Gbps | 48 x 10G SFP+ ports 6 x 100G QSFP28 ports | OcNOS-SP-CSR-800 OcNOS-SP-IPBASE-800 OcNOS-SP-MPLS-800 | SP 6.6.0 | Label Revision: R03E CPLD 1 Version : 15 CPLD 2 Version : 7 Fan CPLD Version : 3 ONIE Version : 2020.08.00.08 Diag Version : 01.03.00.22 Firmware Revision : 0.57 CPU CPLD Version: 32.02 | Cables & Transceivers |
| AS7315-27X | Edgecore | QAX | BCM88272_A1 | 300Gbps | 20 x 10GE 4 x 25GE 3 x 100GE | OcNOS-CSR-300 OcNOS-SP-IPBASE-300 OcNOS-SP-MPLS-300 | SP 6.6.0 | Label Revision : R01 ONIE Version : 2018.11.00.09 Diag Version : 01.01.05.42 Switch Chip Revision: BCM88470_B0 Fan Board Id : 3 FPGA PCB version : R01 CPLD Version : 1.18 FPGA Version : 38 Fan CPLD Version : 0.12 | Cables & Transceivers |
| AS7315-30X | Edgecore | QAX | BCM88370 (external TCAM) | 300Gbps | 4 x 1GE 16 x 10GE 8 x 25GE 2 x 100GE | OcNOS-CSR-300 OcNOS-SP-IPBASE-300 OcNOS-SP-MPLS-300 | SP 6.6.0 | Label Revision: R0B CPLD Version: 1.1 FPGA Version: 23 Fan CPLD Version: 0.12 | Cables & Transceivers |
| AS7316-26XB | Edgecore | QAX | BCM88370 | 300Gbps | 16 x 10GE 8 x 25GE 2 x 100GE | OcNOS-CSR-300 OcNOS-SP-IPBASE-300 OcNOS-SP-MPLS-300 | SP 6.6.0 | Label Revision: R0DD CPLD version: 2 FPGA version: 16 Fan CPLD version: 2 | Cables & Transceivers |
| AS4625-54T | Edgecore | TR3-X2 | BCM56277 | 120Gbps | 48 x 10/100/1000Base-T RJ45 6 x 1G/10G SFP+ | OCNOS-DC-IPBASE-120 OCNOS-DC-MGMT-120 | DC 6.6.0 | Label Revision: R01A ONIE Version : 2022.08.00.01 Diag Version : 01.01.00.00 Board CPLD Version: 2.2 | Cables & Transceivers |
| AS7326-56X | Edgecore | TR3-X7 | BCM56873 | 2Tbps | 2 x 10GE 48 x 25GE 8 x 100GE each splittable into 4 x 10GE or 2 x 50GE or 4 x 25GE | OcNOS-DC-IPBASE-2000 OcNOS-DC-PLUS-2000 | DC 6.6.0 | Label Revision: R01G CPLD 1 Version : 2 CPLD 2 Version : 4 CPLD 3 Version : 3 Fan CPLD Version : 211 ONIE Version : 2020.08.00.02 Diag Version : 01.01.01.05 | Cables & Transceivers |
| AS7535-28XB | Edgecore | Q2A | BCM88470 | 800Gbps | 24 x 25GE SFP28 2 x 100GE QSFP28 2 x 400GE QSFP-DD | OcNOS-SP-IPBASE-800 OcNOS-SP-MPLS-800 OcNOS-SP-PLUS-800 | SP 6.6.0 | Label Revision: R02A CPU CPLD version:11 FPGA1 Version: R0B CPLD Version: 11 BMC: AST2600 BMC Firmware Revision: 0.04 Diag Version : 02.02.00.03 ONIE Version : 2020.11.00.14 | Cables & Transceivers |
| AS7712-32X | Edgecore | TH | BCM88470 | 3.2Tbps | 32 x 100GE each splittable into 4 x 10GE or 2 x 50GE or 4 x 25GE | OcNOS-DC-IPBASE-3200 OcNOS-DC--PLUS-3200 | DC 6.6.0 | Label Revision: R02F CPLD 1 Version: 10 CPLD 2 Version: 11 CPLD 3 Version: 11 Fan CPLD Version: 8 | Cables & Transceivers |
| AS7716-24SC (Cassini) | Edgecore | TH+ | BCM56873_A0 | 3.2Tbps | 16 x 100GE each splittable into 4 x 10GE or 2 x 50GE or 4 x 25GE 8 Coherent slots, 200/100GE each 8 | OcNOS-RON-IPBASE OcNOS-RON-XCONNECT OcNOS-RON-MPLS | RON 6.4.2 | Label revision: R01B CPLD1: 7 CPLD2: 7 CPLD3: 7 Fan CPLD: 4 | Cables & Transceivers |
| AS7726-32X | Edgecore | TR3-X7 | BCM88480 | 3.2Tbps | 2 x 10GE and 32 x 100GE each splittable into 4 x 10GE or 2 x 50GE or 4 x 25GE | OcNOS-DC-IPBASE-3200 OcNOS-DC--PLUS-3200 | DC 6.6.0 | Label Revision: R01G Fan CPLD Version : 8 ONIE Version : 2017.11.00.05 Diag Version : 01.01.01.09 CPLD 1 Version : 14 CPLD 2 Version : 142 CPLD 3 Version : 142 Fan CPLD Version : 8 | Cables & Transceivers |
| AS7816-64X | Edgecore | TH2 | BCM56960_B1 | 6.4Tbps | 64 x 100GE each splittable into 4 x 10GE or 2 x 50GE or 4 x 25GE | OcNOS-DC-IPBASE-6400 OcNOS-DC--PLUS-6400 | DC 6.6.0 | Label Revision: R01D CPLD 1 Version : 9 CPLD 2 Version : 3 CPLD 3 Version : 3 CPLD 4 Version : 3 Fan CPLD Version : 7 | Cables & Transceivers |
| AS7946-30XB | Edgecore | Q2C | BCM56965_A1 | 2.4Tbps | 4 x 10GE/25GE SFP28 18 x 100GE QSFP28 4 x 100GE QSFP-DD 4 x 400GE QSFP-DD | OcNOS-SP-IPBASE-2400 OcNOS-SP-MPLS-2400 OcNOS-SP-PLUS-2400 | SP 6.6.0 | Label Revision : R02 ONIE Version : 2020.11.00.18 Diag Version : 02.02.00.08 Switch Chip Revision: BCM88820_A1 BMC Version : 9.02 BMC AUX Version : 0x09.0x00.0x00.0x00 | Cables & Transceivers |
| AS7946-74XKSB | Edgecore | Q2C | BCM56960 | 2.4Tbps | 10 x 100GE QSFP28 64 x 10GE/25GE SFP28 | OcNOS-SP-IPBASE-2400 OcNOS-SP-MPLS-2400 OcNOS-SP-PLUS-2400 | SP 6.6.0 | ONIE Version : 2020.11.00.18 Label Revision : R01 Diag Version : 02.01.00.01 Switch Chip Revision: BCM88820_A1 BMC Version : 0.02 BMC AUX Version : 0x09.0x00.0x00.0x00 | Cables & Transceivers |
| AS9716-32D | Edgecore | TH3 | BCM56980_B0 | 12.8 Tbps | 32 x 400G | OcNOS-DC-IPBASE-12800 OcNOS-DC-PLUS-12800 | DC 6.6.0 | Label Revision : R01C CPLD 1 Version : 2 CPLD 2 Version : 3 CPLD 3 Version : 2 Fan CPLD Version : 242 ONIE Version : 2019.08.00.03 Diag Version : 01.01.00.23 | Cables & Transceivers |
| AS9726-32DB | Edgecore | TR4 | BCM56880_B0 | 12.8 Tbps | 32X400G QSFP56-DD 2X10G SFP+ | OcNOS-DC-IPBASE-12800 OcNOS-DC-PLUS-12800 | DC 6.5.3 | Label Revision: R01F ONIE Version: 2020.08.00.13 Diag Version: 02.01.00.11 FPGA Version: 8 CPLD 2 Version: 7 CPLD 3 Version: 4 Fan CPLD Version: 164 | Cables & Transceivers |
| AS9736-64D | Edgecore | TH4 | BCM56990_B0 | 25.6 Tbps | 16X400G QSFP56-DD(24W) 48X400G QSFP56-DD(13W) | OcNOS-DC-PLUS-25600 | DC 6.5.3 | Label Revision: R01A ONIE Version: 2020.11.00.15 Diag Version: 0a.01.00.19 Fan Board Id: R0D SMB CPLD Version: 22 SMB FPGA Version: 17 UDB CPLD2 Version: 17 Fan CPLD Version: 22 | Cables & Transceivers |
| AS5915-16X | Edgecore | QUX | BCM88273_A1 | 120 Gbps | 4 x 10G ports 12 x 1G ports | OcNOS-SP-CSR-64 OcNOS-SP-IPBASE-64 OcNOS-SP-MPLS-64 | SP 6.6.0 | Label Revision : R0A ONIE Version : 2022.08.00.06 Diag Version : 01.01.01.02 CPLD Version : 1 FPGA Version : 2 | Cables & Transceivers |
| DS1000 | Celestica | TR3-X2 | BCM56277_A1 | 120Gbps | 48 x 10/100/1000Base-T RJ45 8 x 10G SFP+ | OCNOS-DC-MGMT-120 OCNOS-DC-IPBASE-120 | DC 6.6.0 | Label Revision: Belgite Board CPLD Version : 2.6 | Cables & Transceivers |
Disclaimer: This content is for informational purposes and subject to change. Please contact ipisales@ipinfusion.com for any questions.
